SI-1404 - Дополнительная приставка для тестирования Mk12/Modes IFF транспондеров

SI-1404 - Дополнительная приставка для тестирования Mk12/Modes IFF транспондеров
Производитель
Гарантия
12 месяцев
(если иной срок не предусмотрен производителем)
Требуется уточнить цену
В корзину
Купить в один клик
Заказать поверку/калибровку
Задать вопрос
  • Информация о товаре
  • Технические характеристики
  • Комплект поставки
  • Аналоги
  • Оплата и доставка

Описание:

SI-1404 and its companion unit the ATC-1400A Transponder / DME Test Set provide simulation and measurement capability for ATCRBS, Mode S and Mode 4.

The SI-104 combines the features and capabilities of the S-1403DL Mode S and the I-1402 Mode 4 Accessory Units into a single easy-to-use unit. The SI-1404 can be used as a stand alone unit to perform a variety of Mode 4 IFF testing. When combined with the ATC-1400A, the SI-1404 provides microprocessor controlled testing of a single diversity channel IFF transponder.

The SI-1404 provides interface with KIT/KIR/KIV devices or internally generated maintenance codes for verification of IFF operation.

  •  Easy-to-use menus allow rapid setup or recall of test parameters
  •  GPIB interface allows rapid, automated testing of transponders and interrogators
  •  4096 code encoder, altitude encoder and Mode Group delay facilitates IFF testing
  •  Flash memory for easy firmware upgrades
  •  Precise control of ATCRBS, Mode S and Mode 4 pulse characteristics including width, offset and amplitude
  •  User defined screens for user-specific tests
  •  Two Year Limited Warranty
