SDX-2000 signal generator

SDX-2000 signal generator
12
( )
/

:

Designed in consultation with the world's leading Mode-S transponder manufacturers, the SDX 2000 is the first new technology, fully programmable RF tester that provides complete test capability for all commercial and military pulsed L-band avionics: ATCRBS and Mode-S Transponder (including datalink), DME, TACAN, and IFF (Identify Friend or Foe). Here are just a few of the user benefits:

  •  Maximum test capability in a single tester
  •  Increased reliability
  •  Reduced calibration time and expense
  •  Decreased LRU test times
  •  Software easily upgraded in field via floppy disk distribution

The SDX 2000 also has superior technical and operational features:

  •  Active matrix color LCD display simplifies data display
  •  Graphical user interface via acoustic wave touch sensitive screen
  •  Pop-up menus for simplified control
  •  Integral solid-state disk drive for storing commonly used test sequences and semi-automated testing
  •  DSP (Digital Signal Processing) technology improves reliability and reduces calibration requirements
  •  Dual, independent L-Band generators simulate true "signal-in-space" for diversity testing
  •  Fully GPIB programmable for ATE applications

Commercial & Military L-Band Avionics Support

ATCRBS & Mode-S Transponders

  • Transmission and reception of Mode-S ELM (extended length messages)
  •  Transmission and reception of Comm-C and Comm-D Datalink Messages
  •  Two transmit channels for top and bottom antenna diversity testing
  •  Ability to simulate any Mode A, C, S, and Intermode Interrogation
  •  Ability to measure all key reply parameters: Pulse Timing, Power, Frequency, % Reply, Squitter, etc.

Distance Measuring Equipment

  •  Ground Station Simulation
  •  Velocity to 10000 knots
  •  Distance to 400 nmi
  •  Ability to measure all key RF parameters and vary reply pulse parameters
