Unprecedented accuracy in an affordable avionics signal generator

The NAV 2000R is the only generator you need to test ADF, Marker Beacon, VOR, LOC, Glideslope, HF, VHF, and UHF Comm receivers. The NAV 2000R Signal Generator offers a frequency range of 150 kHz to 450 MHz., and is loaded with special avionic functions including the ability to generate Morse Code Ident in VOR and LOC modes, Dot/Dash pulsed audio tones corresponding to the Marker Beacon selected, Two-Tone modulation and SELCAL capability in COMM mode.

All signal parameters are controllable from the front panel or through the standard IEEE-4888 bus for use in manual bench and ATE test applications. STORE and RECALL functions allow quick recall of up to 249 user stored test setups (49 in each mode). The bright electroluminescent display combined with logically grouped keypads provide for fast, efficient setup of avionics test signals.

The most often used signal parameters can be entered with a single keystroke by using hot keys dedicated to VOR bearing and DDM selections. MODE keys along the display access the following avionics functions:

  • VOR - bearing displayed in degrees To/From (radial); user control of 30 Hz variable and 9960 Hz modulation percentage and frequency; user control of 1020 Hz tone modulation with programmable Morse Code Ident capability.
  • Localizer - 90 and 150 Hz modulation displayed in DDM or percent modulation; 90/150 Hz phase control; 1020 Hz tone modulation with user programmable Morse Code capability.
  • Glideslope - 90 and 150 Hz modulation displayed in DDM or percent modulation; 90/150 Hz phase control.
  • ADF - modulations tones variable from 10 Hz to 18 kHz; 1020 Hz tone modulation with user programmable Morse Code capability.
  • Marker Beacon - variable 400 Hz outer marker, 1300 Hz middle marker and 3000 Hz inner marker, with pulsed tone ident capability corresponding to selected beacon type.
  • COMM - modulations tones variable from 10 Hz to 18 kHz with two tone capability for HF applications. SELCAL option allows setup of ARINC 714-6 selective calling tones.
  • Rear Panel Video
  • Front Panel Control of Video Level for use with NAV Converters
  • Front Panel Store Recall allows for 49 Setups per Mode, 294 Total
  • Digital Signal Processing (DSP)
  • IEEE-488 Interface Standard - Full bus control of all features
